Precisely cut up to 2 mm thick material

The new EdgeCut has not only been completely redesigned, the new slitting and winding machine also performs to the most recent engineering best practice and is part of düspohl’s latest developments. The new system not only minimises the potential hazard to the operator, but also shortens setup times dramatically.

Automatic positioning

The newly developed düspohl cutting system makes it possible to cut and wind absolutely free of burrs and crease-whitening. The result is the highest quality thin papers, thermoplastic films and up to 2 mm thick edging materials, such as ABS or PVC. One of the biggest challenges was the firm commitment to enable fully automatic knife positioning such as possible with the established AutoCut. The user specifies the desired cutting widths individually via touchscreen or retrieves them from a database. The adjustment process is completed in less than two minutes and guarantees a cutting width tolerance of no more than +/- 0.1 mm.

Outstanding Winding Quality

Two distance sensors, among other things, ensure outstanding winding quality. They continuously sense the material rolls and control the braking force and the drives accordingly, depending on the roll diameter. The ideal process speed and web tension is thus held constant and perfectly controlled in combination with the drive power. 8 mm friction elements on the winding shafts allow very finely adjusted, width-dependent traction distribution across the cut material during the winding process.

Features:

• The knife system is suitable for materials such as paper, veneer, laminate, ABS, PVC, PP and other materials.
• Material thickness: 0.1 mm to 2 mm.
• Working width up to 700 mm.
• Strip width min.: 18 mm.
• Roll diameter max.: 700 mm.
• Cutting speed: 10-150 m/min.



---
